For Residential and Mid-Low Traffic Commercial Buildings
Door Cycles per Year: Up to 800.000
Traffic Peak of the Door: Up to 240 cycles per hour
Lift Speed: Up to 2.5m/s
| DIMENSIONS | ||||
| Door Opening Type | Min. Clear Opening (mm) | Max. Clear Opening (mm) | Min. Clear Height (mm) | Max. Clear Height (mm) |
| C2 - T2 | 700 | 1400 | 2000 | 2200 |
| STANDARDS | ||||
| Door Opening Type | EN81-20/50 Safety Rules | EN81-71 Vandal Resist. | EN81-72 Firefighter Lifts | EAC |
| C2 - T2 | ✓ | - | ✓ | ✓ |
| PROTECTIONS | ||||
| Door Opening Type | IP21 | IPX3 | IP54 | IP65 |
| C2 - T2 | ✓ | ✓ | - | - |
